ZS-NJ-D933 RTV Silicone Adhesive Sealant

Clear RTV Silicone Adhesive and Sealant, ZS-NJ-D933

Description

ZS-NJ-D933 RTV silicone adhesive sealant is a one-component, low viscosity, dealcoholized silicone sealant which cures at room temperature. This product is designed to offer excellent adhesion to many substrates such as copper, aluminum, stainless steel, etc. Superior electric properties and heat resistance allows a temperature range of -60℃～200℃. Alcohols are released during curing but are non-corrosive to PC, copper, etc. Fully complies with EU ROHS and REACH standards.

Typical applications

Photoelectricity: Bonding and waterproof sealing of LED tube and LED bulb
Bonding, sealing engineering plastics, metal, glass, ceramic
Bonding, fixing, strengthening, waterproof sealing electronic components onto PCBs

Technical specs

Uncured properties	Appearance	Translucent, semi-flowable
	Tack free time (min)	≤15
	Viscosity (cps，25℃)	10000~16000
	Cure through time (d)	3～7
Cured properties	Specific gravity (g/cm3)	0.95～1.05
	Hardness (Shore A)	15～20
	Tensile strength (MPa)	≥0.5
	Shear strength (MPa)	≥0.5
	Elongation (%)	≥200
	Temperature resistance (℃)	-60～200
	Volume resistivity (Ω·cm)	≥1.0×1014
	Dielectric Strength (kV/mm)	10
	Dielectric constant (1.0MHz)	2.0~2.5

Note:

The performance data above are measured for 7 days after curing at 25℃ and 55% relative humidity.
The tack free time becomes longer with the storage time increases.
Zhaoshun cannot assume responsibility for different results obtained under different conditions or caused by product improvement.
