ZS-NJ-D901B RTV Silicone Adhesive Sealant

Electronic Grade Black Silicone Sealant, ZS-NJ-D901B

Description

The ZS-NJ-D901B RTV silicone adhesive sealant is composed of a one-part, room-temperature curing, ketoxime product. This product is semi-flowable, self-leveling, and won’t permeate into small gaps, allowing for a high sealing strength. It cures to an elastomer and offers an excellent resistance to thermal cycling, stress-changing, low and high temperatures. This product can maintain elasticity, stability and UV resistance for a long period at temperatures of -60～200℃. During curing, ketoxime is released, which is slightly corrosive to PC and copper materials. It conforms to EU RoHS and REACH standards.

Typical applications

Water and moisture proof sealing, bonding of electronic components
Protective potting of modules
Fixing connectors on circuit boards

Technical specs

Uncured properties	Appearance	Black, semi-flowable
	Tack free time (min)	≤20
	Viscosity (cps, 25℃)	55000~75000
	Cure through time (d)	3～7
Cured properties	Specific gravity (g/cm3)	1.30～1.40
	Hardness (Shore A)	35～45
	Tensile strength (MPa)	≥2.0
	Shear strength (MPa)	≥1.0
	Elongation (%)	≥200
	Temperature resistance (℃)	-60～200
	Volume resistivity (Ω·cm)	≥1.0×1013
	Dielectric Strength (kV/mm)	≥13
	Dielectric constant (1.0MHz)	2.7~2.9

Note:

The performance data above are measured 7days after curing at 25℃ and 55% relative humidity.
The product cures tack free more slowly as the storage time increases.
Zhaoshun cannot assume responsibility for different results obtained under different conditions or caused by product improvement.
