Black Flame Retardant Silicone Adhesive, ZS-NJ-D959B11G

ZS-NJ-D959B11G RTV Silicone Adhesive Sealant

Black Flame Retardant Silicone Adhesive, ZS-NJ-D959B11G
Description

The ZS-NJ-D959B11G RTV silicone adhesive sealant is composed of one-part dealcoholized silicone which cures at room temperature. It features an outstanding dielectric property, excellent heat resistance and wide operating temperature range of -60～200℃. This product is ideal for providing an excellent adhesion to aluminum, copper, stainless steel, ceramics, and more. During the curing process, it generates alcohol, and is noncorrosive to PC, copper, and other materials. It conforms to RoHS standards.

Typical applications
  • Bonding and sealing panel, bottom plate of small home appliances
  • Bonding, sealing and fixing of electronic components
Technical specs
Uncured properties Appearance Black, paste
Tack free time (min) ≤15
Extrusion rate (g/s, 25℃) 40~60
Cure through time (d) 3～7
Cured properties Specific gravity (g/cm3) 1.45～1.55
Hardness (Shore A) 35～45
Tensile strength (MPa) ≥1.5
Shear strength (MPa) ≥1.0
Elongation (%) ≥350
Temperature resistance (℃) -60～200
Volume resistivity (Ω·cm) ≥1.0×1013
Dielectric Strength (kV/mm) ≥13
Flame retardant rating UL94 V-0
Note:
  • The performance data above are measured 7days after curing at 25℃ and 55% relative humidity.
  • The product cures tack free more slowly as the storage time increases.
  • Zhaoshun cannot assume responsibility for different results obtained under different conditions or caused by product improvement.
